| Date | Hours | Reason for Downtime |
|---|---|---|
| 08.10.2013 | 5.0 | IL 224071 (BGM.MOD.DspErrPfndacSteady). |
| 08.10.2013 | 1.5 | IL 224071 (BGM.MOD.DspErrPfndacSteady). |
| 11.10.2013 | 1.5 | DICOM communication error (pic1, pic2) when loading a certain patient plan. No treatment possible on both TrueBeams. Solution: deleted some JPEG images from setup fields. |
| 20.11.2013 | 3.33 | IL 420208 during VMAT (pic). Replaced leaf motor B-17. |
| 27.11.2013 | 1.0 | MV Ready lights up, but Beam On is not possible. No IL. Reboot SPV -> no effect. Emergency Off -> OK. |
| 2013 | 12.33 | |
| 07.01.2014 | 1.0 | Laser Guard Error 1. |
| 24.01.2014 | 1.0 | XI-IL. Reboot digitizer unit (DU). |
| 21.02.2014 | 0.25 | MLC IL 420207. |
| 26.02.2014 | 1.0 | CCHU IL 715602, 715803, 715288, 715822. |
| 11.03.2014 | 0.33 | CCHU IL 715602, 715803. Cleaned with compressed air. |
| 13.03.2014 | 0.75 | Beam-On not possible due to GATE-IL. BGM, XI rebooted. Restart kV gen, MLC init, axis, carr (transverse: 5x). |
| 15.04.2014 | 0.5 | BGM 227135. |
| 05.05.2014 | 0.5 | CCHU IL 715803. |
| 15.05.2014 | 1.0 | X2 jaw does not initialize (reed switch at home position not properly aligned) |
| 23.05.2014 | 1.0 | Failed to close beam loop on BGM. Beam-on not possible (no IL). Beam loop voltages. OK after em-off. |
| 11.06.2014 | 0.5 | CCHU 715803. |
| 13.07.2014 | 2.0 | Failed to close beam loop on BGM. |
| 14.07.2014 | 0.5 | Failed to close beam loop on BGM. |
| 31.07.2014 | 1.0 | XI. No MV image possible. |
| 04.08.2014 | 0.17 | "Power Saver" during arc treatment (IL 206002, 206003, 331054, 331058, 800000, ...) |
| 07.08.2014 | 0.33 | Laser Guard at gantry 180°. STN reboot. |
| 19.08.2014 | 0.25 | "Power Saver" before treatment (no IL). Turn on -> OK |
| 17.09.2014 | 0.17 | CCHU 715803. Cleaned with compressed air. |
| 17.09.2014 | 0.17 | COL 420208 (MLC Leaf B14 prim/sec sensors) during IMRT. |
| 18.09.2014 | 0.5 | kVS HWAPIError. Rebooted kVS node, initialized kVS collimator. |
| 23.09.2014 | 7.5 | MLC: Short on HD 120 Motor Interconnect, Side A. Replaced PCB (pic 1 2MLC 3MLC 4 5 6 7 8 9 10 11). |
| 27.10.2014 | 2.0 | VMS.DSE.OrchestratorHost.exe has stopped working. |
| 27.10.2014 | 0.5 | Lost connection to Supervisor (pic 1, 2, 3). Emergency off, initialized all axes, restarted DICOM stream srv. |
| 29.10.2014 | 3.5 | Replaced noisy water pump in stand. |
| 2014 | 26.42 | |
| 29.04.2015 | 1.0 | During MPC: COMM 309131, no sounds from DKB. Reset DKB, reboot TrueBeam console, reboot STN node. |
| 04.05.2015 | 0.17 | Image artefacts during Pelvis CBCT (pic1, pic2). Calibrated kV baldes. |
| 15.05.2015 | 0.17 | kVS-IL 1001005: reboot, init, OK. |
| 04.05.2015 | 0.67 | MV Ready, but Beam-On not possible. Emergency Off, OK; XI disconnect: reboot XI, OK. |
| 09.06.2015 | 0.25 | MLC-IL 420207 during LF-IMRT (A-52). Init OK, Resume treatment with same IL. Resume on other machine. |
| 09.06.2015 | 2.00 | MLC-IL 420207 during VMAT. Init MLC. Again same IL, reproducible in Plan-QA, always on A side (A-52, 10, 6, 20). Calibration of MLC. |
| 11.08.2015 | 1.0 | No MV/kV imaging. Reboot XI, IRM, TrueBeam, DU. |
| 13.08.2015 | 2.0 | No kV imaging ("No valid kV setting found". "There is no mapping defined ..."). -> Varian via SmartConnect. |
| 13.08.2015 | 0.5 | IL 101006. Rebooted BGM. |
| 24.08.2015 | 0.25 | MLC-IL. Initialized. |
| 27.08.2015 | 0.25 | 8:00: MLC-IL (B-40). Initialized. |
| 27.08.2015 | 0.25 | 10:45: MLC-IL (B-40). Initialized. |
| 10.09.2015 | 0.33 | 8:00: MLC-IL (B-10). |
| 10.09.2015 | 0.33 | 8:30: MLC-IL (B-10). |
| 10.09.2015 | 0.75 | 11:30: MLC-IL (B-10). |
| 15.09.2015 | 0.25 | 10:00: MLC-IL (B-10). |
| 25.09.2015 | 0.25 | 8:40: Col.SW.Y2.PrimSecDiff (416000). Initialized Y. |
| 02.10.2015 | 0.5 | 6:00: MV-Ready, but cannot beam-on. Power down complete system. Then CCHU. |
| 23.10.2015 | 0.17 | MLC-IL (A-45). Initialized MLC. |
| 04.11.2015 | 2.0 | After power failure: VMS.DSE.Orchestrator.EXE stopped working. Reboot DU, kV generator, XI, ... |
| 02.12.2015 | 0.17 | TB suddenly falls into Standby. Time delay 5 mins, MLC init. |
| 2015 | 13.26 | |
| 29.01.2016 | 0.75 | 12:00 CCHU interlocks + Power Off -> Varian. Restart. |
| 29.03.2016 | 1.0 | 6:30: IL 1001005 (HWAPIError), then beam is not enabled (IL 100106, BELSwitchFailed). EM-Off in Service Mode, init all axes. |
| 06.05.2016 | 3.5 | Rebuild TrueBeam RAID after HD removal. Mouse defective. |
| 09.05.2016 | 0.5 | 16:30 Beam-off at 6E. IL at BGM subnodes MOD and EGN. Reboot BGM: not OK. Emergency Off. Init all axes. |
| 19.07.2016 | 0.25 | No "MV Ready". IL Node 2. BGM reboot. |
| 17.08.2016 | 0.25 | MLC-IL 420224 (B-29). Doses not initialize. B-29 does not move manually. |
| 21.11.2016 | 2.0 | 18:00: RF Driver dead. |
| 22.11.2016 | 4.0 | Installation of new RF Driver. |
| 28.12.2016 | 0.17 | 12:56 MLC IL 420219 (trajectory A-35) |
| 2016 | 11.42 | |
| 04.01.2017 | 5.33 | 12:37 Squeaking target sledge. IL 216219 (PosTarget.SecondaryStuck) |
| 17.01.2017 | 0.17 | 10:41: IL 1012067 etc. Power Off. |
| 19.01.2017 | 1.0 | 10:00: MLC IL 420207. Replaced leaf motor A-31. |
| 07.02.2017 | 0.67 | 05:50: Treatment application hangs. |
| 06.04.2017 | 0.5 | 09:00: Replaced leaf motor A-22. |
| 19.05.2017 | 0.33 | 10:38: Trajectory IL 420219 (A-41). Init not possible. Override MLC. Init OK. |
| 19.05.2017 | 0.33 | 11:52: Trajectory IL 420219 (A-41). Init not possible. Override MLC. Init OK. |
| 10.07.2017 | 0.25 | 13:53: LeafAPrimSecOutOfTol (A-44) (ID: 420207). Initialized MLC. |
| 12.07.2017 | 0.5 | 13:55: CCHU 715617 (CouchLngPrimSensor). Cleaned with compressed air, power cycle CCHU sensors. |
| 31.07.2017 | 0.25 | 18:22: Lost connection to IPS (ID: 6022). Reboot Treatment and Reconstructor. |
| 11.08.2017 | 0.5 | 05:48: Power off over night, T=23.9°C. Initialized all axes. |
| 14.08.2017 | 5.5 | 13:20: XI-IL: kVS collimator did not move as commanded (Y1 blade). |
| 16.08.2017 | 2.0 | 06:00: kVS blade IL @ MPC. Then CCHU. Recycle upper couch node. |
| 22.08.2017 | 0.17 | 07:47: DMI.NotReady (ID: 513708). Reboot XI. |
| 22.08.2017 | 0.25 | 16:00: Truebeam keyboard and mouse frozen. Disconnected TB computer from power. Reboot. |
| 23.08.2017 | 0.17 | 07:53: PVA/XI disconnected (ID: 122500). Reboot XI. |
| 23.08.2017 | 0.17 | 10:58: DMI.NotReady (ID: 513708). Reboot XI. |
| 28.08.2017 | 5.0 | 10:15: MLC: Replaced leaf motors A-44, A-40. Installed (used) SF-board. |
| 08.09.2017 | 0.25 | 08:20: LeafAPrimSecOutOfTol (A-20) (ID: 420207). Initialized MLC. |
| 30.10.2017 | 0.67 | 05:58: "Mains" fuse tripped, power off over night, T=22.1°C. |
| 31.10.2017 | 1.0 | 05:50: LeafAPrimSecOutOfTol (A-31) (ID: 420207). Replaced leaf motor A-31. |
| 30.11.2017 | 0.5 | 15:58: After IRM reboot: "Machine monitor is not connected". Full power down (UPS off). |
| 04.12.2017 | 0.33 | 05:45: TrueBeam in Standby. 12 min time delay. |
| 15.12.2017 | 2.0 | 13:45: No hospital water supply. Overtemp. Several problems (pitched couch at end stop) upon recovery. |
| 21.12.2017 | 0.25 | 05:45: TrueBeam in Standby. 12 min time delay. |
| 2017 | 28.09 | |
| 12.01.2018 | 0.33 | 05:45: Modulator: CB8 tripped. TrueBeam in PEL mode. |
| 07.02.2018 | 0.5 | 07:08: IL 420219 (TrajDeviationLeafA). Movement not possible. Replaced motor A-26. |
| 12.02.2018 | 1.67 | 08:55: IL 221225 (MissingModTrigger), 224053 (ESPErrIlhvocMon) 1 2 3 4 -> Varian. |
| 24.04.2018 | 0.5 | 07:02: IL 376001 (EXIO.TempError). Fancoils in TrueBeam computer cabinet not working. |
| 24.04.2018 | 0.33 | 07:11: IL 306200 (HSSBLink3CarrierRxMirrorError) while recovering from heat problems. |
| 24.04.2018 | 0.5 | 07:41: IL 124500 (KVD.Disconnect). Still recovering from heat problems. |
| 08.05.2018 | 0.33 | 09:47: IL 420219 (TrajDeviationLeafA). Movement not possible. Replaced motor A-16. |
| 26.06.2018 | 0.17 | 09:58: IL 420208 (LeafBPrimSecOutOfTol). Initialized, OK. |
| 27.07.2018 | 0.25 | 14:40: IL 420220 (TrajDeviationLeafB). Moved leaf B-29 manually, initialized, OK. |
| 14.08.2018 | 2.25 | 07:08: IL 212110 (Target1LessThanExp), 212111 (Target2LessThanExp). Replaced signal cable. |
| 22.08.2018 | 1.5 | 20:33: IL 611173 (MVDElbow.PrimTertDiff). Failed to initialize arm. |
| 23.08.2018 | 6.25 | Troubleshooting of IL 611173 until 12:45. |
| 24.08.2018 | 2.0 | 08:42: again IL 611173 (MVDElbow.PrimTertDiff). Rotated resolver, OK. |
| 11.09.2018 | 1.0 | 06:47: again IL 611173. Deactivated MVD (kV imaging only). Replaced primary sensor, OK. |
| 20.11.2018 | 0.5 | 13:27: IL 371000 (EXGI.Channel2GeneralFault). Reboot STN> PEL mode> EM off> IL PWM> reboot PWM> OK |
| 29.11.2018 | 7.0 | 05:50: IL 210005 (Dose). No beam output. OrchestratorHost.exe crashed. IL 3016 (CB1). Replaced CB1. |
| 2018 | 25.08 | |
| 29.01.2019 | 0.67 | 17:40: Leaf A-46 won't move; init not possible -> Varian. |
| 11.02.2019 | 0.33 | 07:17: IL 420219. TrajDeviationLeafA. A-43 can't be moved. Replaced motor. Init -> OK. |
| 13.02.2019 | 0.17 | 16:57: IL 420220. TrajDeviationLeafB. B-49 moves again after MLC off/on. Init -> OK. |
| 01.03.2019 | 0.17 | 15:10: IL 1011800. KVS.SW.KVFilterFoil.PrimSecDiff. Srv mode, init KVS ->OK. |
| 07.03.2019 | 0.33 | 08:06: IL 420220. TrajDeviationLeafA. A-49 can't be moved. Replaced motor. Init -> OK. |
| 07.03.2019 | 1.5 | 11:05: TB in PEL mode. During init, MVD cover collides with base. Bypassed, replaced switches. |
| 05.04.2019 | 2.0 | 14:15: TB goes to OFF during kV imaging. CB8 in modulator defective -> replaced. |
| 06.05.2019 | 0.5 | 15:30: TB alphanumeric keyboard stopped working. Replaced keyboard, reboot TB & inroom computer. |
| 08.05.2019 | 0.33 | 13:01: Leaf A-31. init failed, moved manually, init OK. |
| 09.05.2019 | 0.5 | 09:29: IL 306200. STN.SW.COMM.HSSBLink3CarrierRxMirrorError. Stby, off, 3 min time delay, OK |
| 13.05.2019 | 0.33 | 07:51: Platform server not responding. Restart, login admin, check service, login Varian, OK. |
| 13.05.2019 | 0.5 | 08:14: IL 420208 LeafBPrimSecOutOfTol. Several attempts (init, moved, ...) Finally replaced motor. Init -> OK. |
| 24.05.2019 | 0.25 | 14:00: "Processing control system status message failed" Treatment freezes after CBCT. Ctrl+Alt+Shift+R, Reboot TRT & IRM. |
| 24.05.2019 | 0.5 | 14:28: Treatment freezes. No IL. Reboot TRT, IRM, XI (no communication to PVA tasks). |
| 14:06.2019 | 0.16 | 07:14: IL 812600. CCHL.SW.CouchVrt.PrimSecDiff. Moved couch beyond 55cm -> no IL. |
| 20.09.2019 | 3.5 | 09:00: IL 420208 (LeafBPrimSecOutOfTol), leaf 42. Replaced B-iso board. |
| 23.09.2019 | 0.5 | 06:20: TrueBeam in PEL mode. Reboot, init all axes. |
| 03.10.2019 | 0.33 | 05:50: TrueBeam in PEL mode. Reboot, init all axes. |
| 24.10.2019 | 0.5 | 07:26: IL 512230 (XI.SW.KV.Generator.VDCError). Reboot XI and X-ray generator (2x). |
| 27.11.2019 | 0.17 | 08:35: IL 420219 (TrajDeviationLeafA). Replaced motor 9. |
| 09.12.2019 | 0.17 | 17:44: IL 420220 (TrajDeviationLeafB). Init, cycled several times. |
| 13.12.2019 | 0.17 | 16:18: IL 420208 (LeafBPrimSecOutOfTol), leaf 57. Init, OK. |
| 19.12.2019 | 0.17 | 07:58: "Processing the control system status failed.". Unhandled exception ... Reboot treatment. |
| 2019 | 13.75 | |
| 10.01.2020 | 0.5 | 10:23: TB goes to PEL Mode. CB9(REG) tripped (2x). Init all axes, OK. |
| 21.01.2020 | 0.17 | 13:27: IL 420208 (B-34, LeafBPrimSecOutOfTol). Init,OK. |
| 31.01.2020 | 0.33 | 07:06: IL 420219 (A-7, TrajDeviationLeafA). Replaced motor. |
| 21.01.2020 | 0.33 | 06:21: XI not connected. Reboot XI (2x), Reboot Treatment. |
| 25.02.2020 | 0.34 | 11:26: IL 420223 (TrajDriftLeafA). No movement A-41 -- A-43. Replaced motor A-42. |
| 03.03.2020 | 3.0 | 08:48: IL 420208 (B-7), again 11:24 -> Varian. |
| 05.03.2020 | 0.25 | 07:03: IL 420220 (B-29, TrajDeviationLeafB). Replaced motor. |
| 03.04.2020 | 0.17 | 07:12, 08:09: Live Camera fails (pic1, pic2). Reboot Treatment, check all connections. |
| 08.04.2020 | 0.25 | 08:37: IL 420219 (A-33). Replaced motor. |
| 17.04.2020 | 0.33 | 10:00: CBCT artefacts. Calibrated CBCT modes. |
| 21.04.2020 | 0.16 | 10:39: IL 420219 (A-50). Init, OK. |
| 30.04.2020 | 10.67 | 06:02: PEL mode, CB8 tripped. Troubleshooting in modulator (1, 2, 3, 4, 5, 6). Replaced contactor K7. |
| 15.05.2020 | 0.16 | 10:40: IL 420220 (B-40, B-45). Init -> OK. |
| 26.05.2020 | 3.0 | 07:22: Accessory mount - intermittent triggering of IL (pic1, pic2). Replaced code reader PCB. |
| 26.05.2020 | 0.16 | 12:50: "Interoperability error. ADI could not communicate through XBridge." (pic). Restarted Treatment. |
| 06.07.2020 | 2.5 | 09:36: Power Off. Behavior like EM-Off. Troubleshooting all EM-Off switches. |
| 07.07.2020 | 0.33 | 17:20: IPS not running after reconstructor reboot. Rebooted again, OK. |
| 13.08.2020 | 0.17 | 07:17: MV-imager cover mechanical collision after safety check. Screw loose. |
| 03.09.2020 | 5.5 | 06:08: Power outage following iCBCT reconstruction. Reconstructor trips fuse. |
| 02.11.2020 | 5.0 | 06:00: Mains CB8 tripped. IL 310425 (Cooling.AccelGuideFlowLow) (1, 2) |
| 20.11.2020 | 1.0 | 11:20: Power outage following iCBCT reconstruction. Em-Off in GE-Breaker Box under suspicion. |
| 23.11.2020 | 0.58 | 06:08: Power outage. Em-Off in GE-Breaker Box replaced. |
| 14.12.2020 | 4.5 | 05:55: IL 210016, 211100, 222059. 2A-fuse on hotdeck blown. Crowbar replaced (1, 2, 3, 4, 5) |
| 2020 | 39.4 | |
| 13.01.2021 | 0.33 | 07:53: IL 420219 (MLC.TrajDeviationLeafA-41). Replaced motor. |
| 03.02.2021 | 0.16 | 12:14: IL 222002 (EGN.DspErrAdcmonError). Reboot EGN subnode. |
| 11.03.2021 | 0.33 | 07:15: IL 420219 (MLC.TrajDeviationLeafA-43). Replaced motor. |
| 24.03.2021 | 0.33 | 09:14: IL 420219 (MLC.TrajDeviationLeafA-12). Replaced motor. |
| 12.04.2021 | 0.33 | 09:11: IL 420220 (MLC.TrajDeviationLeafB-03). Replaced motor. |
| 26.05.2021 | 0.16 | 14:25: IL 1011800 (KVFilterFoil.PrimSecDiff) > kVS Axes Calib > OK |
| 11.06.2021 | 3.0 | 11:43: IL 224050 (MOD.DspErrIlhvcbMon) after Power Off -> Varian > Crowbar defective. |
| 15.06.2021 | 0.33 | 10:46: IL 420208 (LeafBPrimSecOutOfTol, B-40). Also same field, same MU next day. Init > OK. |
| 30.06.2021 | 1.0 | 13:59: IL 415513 (FPGA.Y1.MotorDriverFault) -> Varian |
| 02.07.2021 | 3.0 | 05:58: IL 222068 (EGN.DspErrHdadcgridvMon) -> Varian |
| 08.07.2021 | 0.33 | 09:22: IL 420207 (LeafAPrimSecOutOfTol, A-18). Replaced motor. |
| 14.07.2021 | 0.16 | 06:59: IL 420207 (LeafAPrimSecOutOfTol, A-18) > Cycle MLC > OK |
| 24.08.2021 | 0.16 | 14:20: IL 420224 (MLC.TrajDriftLeafB-42). MLC init > OK |
| 30.08.2021 | 0.16 | 16:33: IL 510102 (XI.SW.TRANSFER.Error), IL 501017 (XI.SW.COMM.HBPeriodOutOfRange). Reboot XI. |
| 14.09.2021 | 0.5 | 14:45: IL 420219 (MLC.TrajDeviationLeafA-16). Replaced motor. |
| 19.09.2021 | 0.33 | 09:48: IL 420219 (MLC.TrajDeviationLeafA-49). Replaced motor. |
| 28.09.2021 | 0.33 | IL 420205 (CarriagAPrimSecOutOfTol) multiple times. Replaced encoder strip (photo) on A side. |
| 29.09.2021 | 0.33 | 07:23: IL 420208 (LeafBPrimSecOutOfTol, B-40). Replaced motor. |
| 27.10.2021 | 0.33 | 11:08: IL 420220 (MLC.TrajDeviationLeafB-42). Replaced motor. |
| 08.11.2021 | 0.33 | 15:26: IL 420219 (MLC.TrajDeviationLeafA-55). Override IL in service mode > Init > Autocycle > OK. |
| 17.11.2021 | 0.5 | 17:20: IL 363002, 363004 (LaserGuard). Deactivated in SysAdmin > Sync in SrvMode > reboot Stand > Tdly |
| 18.11.2021 | 0.16 | 18:00: IL 420219 (MLC.TrajDeviationLeafA-27). Replaced motor. |
| 22.11.2021 | 0.83 | 06:30: Patient plan load not possible due to DICOM communication error -> Varian |
| 23.11.2021 | 0.16 | 10:28: IL 420208 (LeafBPrimSecOutOfTol, B-40). Init > OK |
| 26.11.2021 | 0.16 | 07:04: IL 420224 (MLC.TrajDriftLeafB-48). MLC init > OK |
| 30.11.2021 | 0.33 | 05:34: TB in PEL Mode, CB8 tripped. Trips multiple times, then OK |
| 10.12.2021 | 0.33 | 11:53: IL 420219 (MLC.TrajDeviationLeafA-46). Replaced motor. |
| 2021 | 14.4 | |
| 18.01.2022 | 0.25 | 06:59: IL 420219 (TrajDeviationLeafA), replaced motor A-29 |
| 23.02.2022 | 0.25 | 09:58: IL 420207 (LeafAPrimSecOutOfTol). replaced motor A-33 |
| 07.03.2022 | 0.33 | 15:10: IL 420207 (LeafAPrimSecOutOfTol, A-33). Initialized MLC (3x) |
| 07.03.2022 | 0.25 | 16:14: After Reconstructor reboot no connection to IPS service. Repeat Reconstructor reboot. |
| 25.03.2022 | 0.5 | 12:15: IL 420219 (TrajDeviationLeafA), replaced motor A-26 |
| 04.04.2022 | 0.25 | 08:30: IL 420220 (TrajDeviationLeafB), replaced motor B-18 |
| 26.04.2022 | 0.25 | 07:15: IL 420208 (LeafBPrimSecOutOfTol, B-23), init, moved manually, calibrate MLC |
| 23.05.2022 | 0.75 | 06:29: TrueBeam in PEL mode, CB8 tripped several times, restarted all components |
| 14.06.2022 | 0.25 | 11:45: IL 420219 (TrajDeviationLeafA), replaced motor A-43 |
| 21.06.2022 | 1.0 | 16:36: IL 420218 (TrajDeviationCarriageB), replaced carriage motor B |
| 14.07.2022 | 0.33 | 05:48: TrueBeam in PEL mode, CB8 tripped, init MLC |
| 20.07.2022 | 4.0 | 17:10: IL 420219, 420150, MLC init not possible |
| 27.07.2022 | 1.0 | 16:11: IL 420218 (TrajDeviationCarriageB), init not possible, replaced carriage motor B + 3 leaf motors |
| 18.08.2022 | 0.33 | 08:34: IL 420219 (TrajDeviationLeafA), replaced motor A-20 |
| 02.09.2022 | 1.0 | 06:00: IL 5019, XI could not initialize the kV detector correctly, reboot XI, CBCT, STN |
| 14.09.2022 | 0.75 | 14:17: I L224050 (HV Crowbar not closed) -> Varian |
| 30.09.2022 | 1.17 | 08:10: IL 420219 (TrajDeviationLeafA), replaced T-nut of leaf A-56 |
| 13.12.2022 | 0.33 | 11:42: IL 312002 (GantryRtn.PrimMovingDeviated). STN reboot -> OK |
| 16.12.2022 | 0.33 | 10:56: IL 212110 (Target1LessThanExp), 212111, 212114, 212115, 212129. Re-routed wire. |
| 2022 | 13.32 | |
| 05.01.2023 | 0.17 | 07:09: IL 420217 (TrajDevCarrA), 420218 (TrajDevCarrB), 420219 (LeafBPrimSecOutOfTol, B-1) |
| 09.01.2023 | 0.33 | 16:30: IL 420208, MLC init with override |
| 15.03.2023 | 0.25 | 10:21: IL 135500, 100020, 135017, BGM reboot, init all axes |
| 04.05.2023 | 3.33 | 10:55: IL 221225 (MissingMODTrigger). Replaced Thyratron + capacitor. |
| 08.05.2023 | 0.5 | 06:00: IL 227302 (HW_INTL_28V_NOTGOOD) etc. Power cycle SPV -> OK |
| 17.07.2023 | 0.17 | 09:11: IL 420208, replaced B-1 |
| 22.08.2023 | 2.5 | 05:33: IL 310411 etc. CB2 (pump) tripped, replaced 6A rated fuse by 8A. |
| 10.09.2023 | 0.17 | 13:21: IL 420207 (LeafAPrimSecOutOfTol, A-41). Initialized MLC. |
| 06.10.2023 | 0.42 | 12:36: IL 420207 (LeafAPrimSecOutOfTol, A-15). Init. MLC OK, again IL, Calibrated MLC -> OK. |
| 22.11.2023 | 0.17 | 13:27: IL 420208 (LeafBPrimSecOutOfTol, B-40). Initialized MLC. |
| 29.11.2023 | 0.17 | 07:08: IL 416000 (COL.SW.Y2.PrimSecDiff). Calibrated Y-jaws. |
| 2023 | 8.18 | |
| 31.01.2024 | 0.25 | 17:28: IL 420219 (TrajDeviationLeafA) A-17, later A-39; Calibate MLC > OK. |
| 01.02.2024 | 0.25 | 11:37: IL 420207 (LeafAPrimSecOutOfTol) A-39; Calibrate MLC > OK. |
| 05.02.2024 | 0.17 | 13:00: IL 420207 (LeafAPrimSecOutOfTol) A-39; Init MLC > OK. |
| 06.02.2024 | 4.0 | 05:56: IL 420207 (LeafAPrimSecOutOfTol) A-39; Varian replaces secondary feedback board > OK. |
| 16.02.2024 | 5.0 | 06:48: IL 1013943 (KFFilterShape.AxisDidNotMoveAsCommanded) > lubricated spindle |
| 11.04.2024 | 0.5 | 12:11: IL 363002, 363004 (LaserGuard), blinking E1; reboot STN > OK. |
| 26.04.2024 | 0.5 | 07:00: MPC: water over-temp (> 48°). Power Off. Waiting for Juniper. Init all axes. |
| 29.04.2024 | 3.0 | 06:15: IL 430052, 430054, ... COL.SW.ACC1.InstallSwitchFail; replaced accessory reader |
| 22.05.2024 | 6.0 | 09:08: 24V stand power supply defective; replaced PS. |
| 22.08.2024 | 6.33 | 18:17: IL 911173 (kVDElbow.PrimTertDiff). Rotated resolver on kVD elbow. |
| 23.08.2024 | 0.17 | 13:18: IL 415000 (COL.SW.Y1.PrimSecDiff). Initialized jaws. |
